NSN : 5805-01-521-1320
- SPECIFICATION

● TA-121/PT Microphone
- Type : Electro Magnetic
- Sensitivity : More than 18dB (1Khz)
- Impedance : 600ohm ± 60ohm (1Khz)
- Frequency range : 0.3~4Khz
- Termination : Contact Ring
- Weight : 59.5g
- Dimensions(inch) : 51.0 pie x 20
- Ambient Temperature : -20℃~60℃
- Humidity : Max 95% RH
- NSN : 5965-00-341-9312

● TA-118/PT Earphone
- Type : Electro Magnetic
- Sensitivity : More than 94dB (1Khz)
- Impedance : 600 ohm ± 60ohm (1Khz)
- Frequency Range : 0.3~4KHz
- Termination : Contact Ring
- Weight : 57.5g
- Dimensions(inch) : 51.0 pie x 18
- Ambient Temperature : -20℃~60℃
- Humidity : Max 95% RH
- NSN : 5965-00-341-9311

● Parts List
1. CASE,TEL 5985-00-543-1881 (SM-D-143140) : Without strap
(SC-DL-170363) : With strap
2. VISUAL INDICATOR 5965-00-698-0430(SM-C-168967)
3. GENERATOR 5805-00-698-0429(SM-D-189375)
4. BUZZER 6350-00-698-0417(SM-C-189639)
